Premade Bag Vacuum Packing Machine
Bag Given Vacuum Packing Machine
Model No. : SW - 130ZK / 160ZK
Packing Speed: 20 to 70 bags / min
(Depends on products' type and filling volume)
suitable packaging bag types
Suitable for all kinds of pickles, dried bean curd, dry fish, meat products, chicken feet, peanuts and other materials which need vacuum packaging.
Machine Parameters & Specification
| Machine Parameters | Specifications |
|---|---|
| Packing Bag Size | Width (W): 80-160mm, Length (L): 80-240mm |
| Packing Speed | 20-70 bags/min |
| Filling Range | 10-50g |
| Gross Weight | Approximately 1200kg |
| Air Consumption | ≥0.8m3/min (Compressed air to be provided by the customer) |
| Voltage | 380V/220V |
| Total Power | 4KW (Includes vacuum pump but excludes feeding elevator) |
Note: The packing speed and filling range will vary depending on the material type.
Features
- Filling stations that handle pre-made bags in one automatic packaging system.
- Automatic placement and transfer of bags into the proper position for packaging.
- Siemens PLC control supports touch-screen operation.
- Extensive choice of languages for use.
- Automated machine can print date codes.
- 304 stainless steel.
- A secure environment is provided in memory for 100 product recipes.
- Gripper size, machine speed, sealing temperature, and filling volume are all stored in production parameter memory.
- Bag deflation is controlled by either wire guide or push bars.
- The two-stage sealing system ensures no product remains.
- Cooling station designed for liquid.
Gross Weight
1200 KG
Filling Rage
10-50g(General Range)
10-50g(General Range)
Working Process
Film Material
Laminated rollstock film, laminated paper roll stock film, aluminum foil roll stock film, etc.
Provides different program according different materials
ShengWei utilize food-grade 304 stainless steel for both the machine body and areas in contact with materials for this Automatic Vacuum Pouch Packing Machine, ensuring safe packaging for food products. Additionally, we tailor our packaging solutions to the specific characteristics of the materials, providing precise and customized packing programs.
