Automatic Pillow Pouch Packing Machine

Liquid: Detergent, soy sauce, vinegar, juice, beverage, jam, chili sauce, bean paste, etc.
Granule: Chips, candies, nuts, dried fruits, biscuits, hardware, toys, and other granule solid-type weighable products.
Powders: Flour, seasoning, milk powder, glucose, chemical seasoning, pesticides, fertilizers.
Compound type: Hotpot condiment, pulp jam.

Automatic Pillow Pouch Packing Machine Catalogues

ShengWei Automatic Pillow Pouch Packing Machine

Introducing ShengWei newest cutting-edge model, featuring the intelligent control system powered by Siemens PLC from Germany and equipped with components from globally renowned brands. This state-of-the-art Collar Type Packing Machine ensures highly efficient and smart fully-automatic operations, seamlessly handling processes from bag retrieval to filling and sealing.

The machine's body is crafted from food-grade #304 stainless steel, guaranteeing exceptional quality and stable performance. Trust in our commitment to excellence as we bring you top-notch technology for your packaging needs.

How does Automatic Pillow Pouch Packing Machine Work?

Bag Forming Phase: Unwinds the film roll and passes it through a forming collar that shapes the film into a tube. The vertical seal bar seals the film along the back.
Date Coding: Prints the date and batch code on the film before it is cut into bags.
Pouch Opening and Inflation: Cuts the film tube into individual bags and opens them with suction cups. Injects air or nitrogen into the bag mouth, inflating it, to prepare them for product filling.
Filling System: Synchronizes with the filler, such as cup filler, auger filler, linear weigher, or multi-head weigher, to dispense the product into the bag. The product type and weight are controlled by the filler.
Sealing and Dispatch: Seals the bag mouth with a horizontal seal bar and cuts off the excess film. The sealed bags are sent out on a conveyor belt or a rotary table.

Working Process

Characteristic

Full automatic feeding, sending material, printing date, install the double roll film structure which can automatically change the film and no need stopping the machine, save the time and effort.
